WC67K-63T 2500mm Hydraulic Bending Machine 7 Feet Tp10s Servo Motor

    Buy cheap WC67K-63T 2500mm Hydraulic Bending Machine 7 Feet Tp10s Servo Motor from wholesalers

    Buy cheap WC67K-63T 2500mm Hydraulic Bending Machine 7 Feet Tp10s Servo Motor from wholesalers
    • Buy cheap WC67K-63T 2500mm Hydraulic Bending Machine 7 Feet Tp10s Servo Motor from wholesalers
    • Buy cheap WC67K-63T 2500mm Hydraulic Bending Machine 7 Feet Tp10s Servo Motor from wholesalers
    • Buy cheap WC67K-63T 2500mm Hydraulic Bending Machine 7 Feet Tp10s Servo Motor from wholesalers

    WC67K-63T 2500mm Hydraulic Bending Machine 7 Feet Tp10s Servo Motor

    Ask Lasest Price
    Brand Name : AOXUANZG
    Model Number : WC67Y-63T/2500
    Certification : CE
    Price : $13698unit
    Payment Terms : L/C, T/T, Western Union, D/P, D/A
    Supply Ability : 500sets/Year
    Delivery Time : 20-30 days
    • Product Details
    • Company Profile

    WC67K-63T 2500mm Hydraulic Bending Machine 7 Feet Tp10s Servo Motor

    WC67K-63T 2500mm Hydraulic Bending Machine 7 Feet 3mm Carbon/Stainless Steel Press Brake Tp10s Servo Motor

    WC67K series bending machine is equipped with servo motor, which has high precision and strong operability. And according to the needs of customers, we can add laser protection and manual electric compensation, etc.


    Main Features:


    1. Special numeric-control system is fitted with mainframe of the bending machine.
    2. Multi-work-stop programming function is able to achieve an automatic operation and continues positing of multi-step procedures, as well as an automatic precision adjustment for positions of rear stopper and gliding block.
    3. The machine is provided with bend counting function, for a real-time display of processing quantity and power-failure memory of positions od stopper and gliding block, as well prccedures and paremeters.

    WC67K-63T 2500mm Hydraulic Bending Machine 7 Feet Tp10s Servo Motor
    The standard cofiguration:

    High precision backguage
    Germany Bosch Rexroth safety valve
    Germany EMB Hose connector
    Schneider Electric System
    WC67K-63T 2500mm Hydraulic Bending Machine 7 Feet Tp10s Servo Motor

    Details:

    WC67K-63T 2500mm Hydraulic Bending Machine 7 Feet Tp10s Servo MotorWC67K-63T 2500mm Hydraulic Bending Machine 7 Feet Tp10s Servo MotorWC67K-63T 2500mm Hydraulic Bending Machine 7 Feet Tp10s Servo MotorWC67K-63T 2500mm Hydraulic Bending Machine 7 Feet Tp10s Servo MotorWC67K-63T 2500mm Hydraulic Bending Machine 7 Feet Tp10s Servo MotorWC67K-63T 2500mm Hydraulic Bending Machine 7 Feet Tp10s Servo Motor


    Technical Parameters:

    ModelNominal pressure (KN)Worktable Length (mm)Columns Distance (mm)ThroatSliderMaxMainDimension
    DepthStrokeOpenmotorL x W x H
    (mm)(mm)heightPower(mm)
    (mm)(KW)
    WC67Y/K-30/1600300160012802008019031700×900×1650
    WC67Y/K-30/2000300200012802008019031700×900×1650
    WC67Y/K-40/2500400250019002801003205.52600×1100×1900
    WC67Y/K-63/2500630250019003501703805.53100×1450×2050
    WC67Y/K-80/3200800320027003501703807.53500×1550×2100
    WC67Y/K-100/32001000320027004002004207.53500×1580×2400
    WC67Y/K-160/3200160032002700400200420113500×1650×2550
    WC67Y/K-200/3200200032002700400200420153500×1680×2550
    WC67Y/K-250/3200250032002700400200420153500×1700×2600
    WC67Y/K-320/3200320032002700400200420223500×1800×2730
    WC67Y/K-400/4000400040003500500320600304300×2450×3500
    WC67Y/K-500/5000500050003900500320600375400×2810×4300
    WC67Y/K-500/6000500060004900500320600376500×2810×4300
    WC67Y/K-500/7000500070004900500320600377500×2810×4900
    WC67Y/K-600/5000600050003900500320600455500×2910×4900
    WC67Y/K-600/6000600060004900500320600456500×2910×5100


    Certifications:
    WC67K-63T 2500mm Hydraulic Bending Machine 7 Feet Tp10s Servo Motor


    Packing Detail:
    Each Hydraulic Press Brake with plastic film package first, then placed in a wooden case, wooden case with a foam filling.
    We loaded the truck with heavy trucks for loading the cargo to the harbor terminal.At the dock we pack the goods in containers
    and ship them abroad.
    WC67K-63T 2500mm Hydraulic Bending Machine 7 Feet Tp10s Servo Motor

    Our Service
    Pre-sales.
    * Project design, performance introduction, technical agreement, contract signing, packaging * Inquiry and consulting support.
    * Sample testing support.
    In-sales. * We will provide you with the latest progress in the product assembly, packaging and transportation.
    After-sales.
    * We will provide free accessories for the damage to non - human parts. * Training how to install the machine, training how
    to use the machine with video and so on * And our technical staff can go abroad to provide technical guidance.


    Customer & EXPO:
    WC67K-63T 2500mm Hydraulic Bending Machine 7 Feet Tp10s Servo Motor
    FAQ:
    1. Are you the manufacture?Can we visit your factory? We are manufacturer and we are located in Anhui,China.And we have our
    own design team for products design. And welcome you visit our factory and check our machine qualtiy on spot,any question will
    be solved on spot at first time.

    2.What's your main product and what is your main foreign market? Our main products are press brake,shears machine,press,cut
    ting machine,locking machine ,auto duct line and related products. Our main foreign market are Asia, North America, Europe, Afr
    ica.

    3. What are the advantages of your machines?And how can i believe the quality of your product? The main configuration is to im
    port quality products, and Professional product quality inspection teamensure machine in top-quality, precision and life. For exam
    ple,Germany Bosch-Rexroth Valve group,Germany Siemens Main Motor,Schneider Electrics system and so on. Once tested as q
    ualified .our machine would be sent out.So The quality of our product is stable and reliable.

    4. Can we be your agent? Yes,we are looking for Global agent we will help agent improve the market ,and supply all the service
    like machine technical problem or other after-sales problem, meanwhile ,you can get big discount and commission.

    5.Are you provide product metal parts and provide us technical guidance? Wearing parts,Disassembly tool(free) are what we cou
    ld provide.And we can give you technical guidance.Our technical staff can go abroad to provide you with technical guidance.
