4*2500mm Cutting CNC Hydraulic Guliitine Shearing Machine With E21S Metal Plate Cutter

Product Description:

This machine makes use of hydraulic driving and swing tool carrier, making it both convenient to operate and maintain. It features complete functions for mechanical back gauge, manual-operated trimming and numerical value display of blade clearance, as well as the "Quick Set" device, and the optional MD11, E21S and TP10S systems.

Moreover, line marking on the plate is also available.

Applications:

QC11K Series Hydraulic Shearing Machine

The QC11K Series Hydraulic Shearing Machine is a powerful tool perfect for cutting various metals. This includes carbon steel, stainless steel, galvanized sheet and aluminum. It is the go-to tool for industrial processes such as metal processing, machine building, building construction, mining, railway construction and aerospace.

This machine is capable of handling multiple tasks with its powerful performance. Its easy to use controls, combined with its efficiency make it the ideal tool for operations requiring inconsistent cuts. With a long list of features, the QC11K Series Shearing Machine gives you precision cuts, no matter the material.

Technical parameter:

​

Model	Thickness (mm)	Cutting Length (mm)	Cutting Angle (°)	Material Strength (KN/CM)	Stroke (times/min)	Power (kw)	Dimension (mm)
4×2500	4	2500	1°30’	≤450	10	5.5	3040*1610*1620
4×3200	4	3200	1°30’	≤450	10	5.5	3840*1610*1620
4×4000	4	4000	1°30’	≤450	8	5.5	4600*1700*1700
4×6000	4	6000	1°30’	≤450	5	7.5	6460*2100*3200
6×2500	6	2500	1°30’	≤450	10	7.5	3040*1610*1620
6×3200	6	3200	1°30’	≤450	9	7.5	3840*1610*1620
6×4000	6	4000	1°30’	≤450	8	7.5	4620*1750*1700
6×5000	6	5000	1°30’	≤450	6	7.5	5400*1750*1700
6×6000	6	6000	1°30’	≤450	5	11	6480*2100*2300
8×2500	8	2500	1°30’	≤450	10	7.5	3040*1700*1700
8×3200	8	3200	1°30’	≤450	8	7.5	3860*1700*1700
8×4000	8	4000	1°30’	≤450	8	7.5	4640*1700*1700
8×5000	8	5000	1°30’	≤450	8	7.5	5400*2400*2000
8×6000	8	6000	1°30’	≤450	8	11	6480*2100*2350
10×2500	10	2500	1°30’	≤450	9	11	3040*1700*1700
10×3200	10	3200	1°30’	≤450	9	11	3860*1700*1700
10×4000	10	4000	1°30’	≤450	8	11	4650*2100*2000
10×6000	10	6000	2°	≤450	5	15	6500*2100*2300
12×2500	12	2500	2°	≤450	9	18.5	3140*2150*2000
12×3200	12	3200	2°	≤450	9	18.5	3880*2150*2000
12×4000	12	4000	2°	≤450	8	18.5	4680*2150*2000
12×5000	12	5000	2°	≤450	6	18.5	5900*2150*2000
12×6000	12	6000	2°	≤450	5	18.5	6900*2600*2700
12×8000	12	8000	2°	≤450	5	18.5	9000*3500*3500
16×2500	16	2500	2°30’	≤450	9	18.5	3140*2150*2000
16×3200	16	3200	2°30’	≤450	8	18.5	3880*2150*2000
16×4000	16	4000	2°30’	≤450	8	18.5	4650*2150*2200
16×5000	16	5000	2°30’	≤450	6	18.5	5900*2600*2700
16×6000	16	6000	2°30’	≤450	5	22	6900*2700*2700
16×8000	16	8000	2°30’	≤450	5	22	9000*3500*3500
20×2500	20	2500	3°	≤450	8	22	3440*2300*2500
20×3200	20	3200	3°	≤450	8	22	4150*2350*2700
20×4000	20	4000	3°	≤450	5	22	4850*2350*2700
20×6000	20	6000	3°	≤450	4	22	4850*2350*2700
25×2500	25	2500	3°	≤450	8	37	3200*2700*2900
25×3200	25	3200	3°	≤450	5	37	4200*2700*2900
30×2500	30	2500	3°	≤450	4	37	3300*2900*2900
30×3200	30	3200	3°30’	≤450	4	40	4200*2900*2900
40×2500	40	2500	4°	≤450	3	75	3200*3300*3000
40×3200	40	3200	4°	≤450	3	90	4300*3300*3200

Details:

Hydraulic Valve
Hydraulic transmission with high reliabilty ,integrated dydraulic system can effectively alleviate problems caused by leakage of hydraulic fluid

Workbench olling Steel Ball
Rlling see bal of workbench can reduce tncto prolet the wokple urfee dlicate desin is convenienfor ctting pelly materials by hand.

Electrical system
Electrical components are imported or from Sino-foreign joint Venture,in accordance with international standards,eliable safety long life,good anti-interference ability.

Blad clearance adjustment
Rapid adjustment mechanism for rearranging blade clearance,easy operation by hand,realizing stepless adjustment of blade clearance

Standard Accessories
1. E21S-Estun: digital monitor to display the position of the back gauge
2. REXROTH, Germany hydraulic system
3. SUNNY, USA oil pump with slide-in pipes joints
4. Back gauge is moved with T-screw shaft, guided by rod-shaft and driven by AC motor
5. Motorized adjustment of blade gap and shearing angle
6. Hydraulic hold downs with sequential operation
7. Moveable foot switch
8. Finger guard
9. Interchangeable blades with four cutting edges
10. One set of standard blade (upper and lower) materials is 6CrW2Si
11. Front support arms with length 1000mm (at least 3pcs)
12. Ball worktable ,reduce the contact between sheet plate and machine work table
13. Often-used internal hexagonal key spanner for adjusting blades
14. Comprehensive instruction & maintenance manual

Support and Services:

Hydraulic Swing Shearing Machine Technical Support and Service

We provide comprehensive technical support and services for our Hydraulic Swing Shearing Machine to ensure that it works correctly and efficiently.

Pre-sales.
* Project design, performance introduction, technical agreement, contract signing, packaging
* Inquiry and consulting support.
* Sample testing support.

In-sales.
* We will provide you with the latest progress in the product assembly, packaging and transportation.

After-sale.
* We will provide free accessories for the damage to non - human parts.
* Training how to install the machine, training how to use the machine with video and so on
* And our technical staff can go abroad to provide technical guidance.

FAQ:

Hydraulic Swing Shearing Machine FAQs

Q: What is the Brand Name of Hydraulic Swing Shearing Machine?

A: The Brand Name of Hydraulic Swing Shearing Machine is Aoxuan.

Q: What is the Model Number of Hydraulic Swing Shearing Machine?

A: The Model Number of Hydraulic Swing Shearing Machine is QC11K-4*2500mm.

Q: Where is Hydraulic Swing Shearing Machine made?

A: Hydraulic Swing Shearing Machine is made in Maanshan.

Q: Does Hydraulic Swing Shearing Machine meet the CE certification?

A: Yes, Hydraulic Swing Shearing Machine meets the CE certification.

Q: What is the Minimum Order Quantity for Hydraulic Swing Shearing Machine?

A: The Minimum Order Quantity for Hydraulic Swing Shearing Machine is 1 SET.

Q: How much does Hydraulic Swing Shearing Machine cost?

A: The price of Hydraulic Swing Shearing Machine is between $6500-$7300.

Q: How is Hydraulic Swing Shearing Machine packaged?

A: Hydraulic Swing Shearing Machine is packaged in LCL.

Q: How long does it take to deliver Hydraulic Swing Shearing Machine?

A: It takes 35 DAYS to deliver Hydraulic Swing Shearing Machine.

Q: What are the Payment Terms for Hydraulic Swing Shearing Machine?

A: The Payment Terms for Hydraulic Swing Shearing Machine is 50% deposit.

Q: How many sets of Hydraulic Swing Shearing Machine can be supplied each year?

A: Up to 300 sets of Hydraulic Swing Shearing Machine can be supplied each year.
