    DA53T 3 / 4 Axis Hydraulic Press Brakes CNC Bending WIth Electric Compensation

    Ask Lasest Price
    Brand Name : Aoxuanzg
    Model Number : WC67Y-125T/3200
    Certification : CE,ISO
    Price : $25430-35620
    Payment Terms : Western Union, MoneyGram
    Supply Ability : 500 sets per year
    Delivery Time : 20-30 working days
    • Product Details
    • Company Profile

    DA53T 3 / 4 Axis Hydraulic Press Brakes CNC Bending WIth Electric Compensation

    DA53T 3 Axis 4 Axis Hydraulic Press Brakes CNC Bending Machine WIth Electric Compensation


    Model

    Nominal pressure

    (KN)

    Worktable Length

    (mm)

    Columns Distance

    (mm)

    ThroatSliderMaxMainDimension
    DepthStrokeOpenmotorL x W x H
    (mm)(mm)heightPower(mm)
    (mm)(KW)
    WC67Y/K-30/1600300160012802008019031700×900×1650
    WC67Y/K-30/2000300200012802008019031700×900×1650
    WC67Y/K-40/2500400250019002801003205.52600×1100×1900
    WC67Y/K-63/2500630250019003501703805.53100×1450×2050
    WC67Y/K-80/3200800320027003501703807.53500×1550×2100
    WC67Y/K-100/32001000320027004002004207.53500×1580×2400
    WC67Y/K-160/3200160032002700400200420113500×1650×2550
    WC67Y/K-200/3200200032002700400200420153500×1680×2550
    WC67Y/K-250/3200250032002700400200420153500×1700×2600
    WC67Y/K-320/3200320032002700400200420223500×1800×2730
    WC67Y/K-400/4000400040003500500320600304300×2450×3500
    WC67Y/K-500/5000500050003900500320600375400×2810×4300
    WC67Y/K-500/6000500060004900500320600376500×2810×4300
    WC67Y/K-500/7000500070004900500320600377500×2810×4900
    WC67Y/K-600/5000600050003900500320600455500×2910×4900
    WC67Y/K-600/6000600060004900500320600456500×2910×5100
    WC67Y/K-600/7000600070005900500320600457500×2910×5200
    WC67Y/K-800/6000800060004900600400600556500×2750 ×5300
    WC67Y/K-800/8000800080006900600400600558500×2750×5900
    WC67Y/K-1000/600010000600049006004006002×376500×2800×5600
    WC67Y/K-1000/800010000800069006004006002×378500×2800×6100
    WC67Y/K-1000/10000100001000080006004006002×3710500×2800×5850
    WC67Y/K-1200/600012000600049006004008002×376500×3100×5850
    WC67Y/K-1200/800012000800069006004008002×378500×3100×7150

    · New EU streamlined design
    · The frame of the bending machine adopts integrated welding and tempering to eliminate internal stress
    · The frame of the bending machine adopts shot blasting to remove rust and is sprayed with anti-rust treatment
    · The frame is formed once by the imported CNC three-dimensional machining center, which ensures the parallelism and perpendicularity of each mounting surface.
    · The controller can control the Y1 and Y2 axes (Y1 controls the left cylinder and Y2 controls the right cylinder) to ensure the synchronous movement of the ram
    · Waiting for quiet speed, fast speed reduction (about 25 decibels), low pressure return noise (the pressure of hydraulic system is controlled by the servo main motor in closed-loop)
    · The main oil pump does not work under the servo main motor drive, and the energy consumption is 60% lower than that of the general CNC bending machine
    · Stable oil temperature, prolonging the service life of each component of the hydraulic system
    · More technological innovations to ensure bending quality, powerful functions and easy operation
    · The bending machine adopts the latest high-frequency hydraulic control technology, which is faster, more efficient and more stable
    · The best parameter ratio, the best core material configuration, stable performance, more convenient operation, can realize the bending of various shapes of complex workpiece.


    DA53T 3 / 4 Axis Hydraulic Press Brakes CNC Bending WIth Electric CompensationDA53T 3 / 4 Axis Hydraulic Press Brakes CNC Bending WIth Electric CompensationDA53T 3 / 4 Axis Hydraulic Press Brakes CNC Bending WIth Electric Compensation
